GARDA shower mixer
- Description
- Chrome, 160 c/c
- Article number
- 96800000
- GTIN
- 7319049680016
PROPERTIES
- With shower connection down
- Pressure balanced thermostatic mixer
- With ceramic sealed headwork
- Temperature handle with safety stop at 38°C
- With Eco-function
- Approved non-return valves, EN-Standard EN1717
![EB](/ui-dist/images/K Skyddsmodul EB.png)
![K Garda Säkerhetsblandare 160cc och 150cc och 40cc.jpg](/storage/320A93C231DB3601FF4B32D5AC4D718B10D8B1080E327F9B2563D0456A04E80F/2611d8a845c94a9ab3c98922c2a0804d/jpg/media/1cab715a13dd409aa9e1682bfc6e18d9/K%20Garda%20S%C3%A4kerhetsblandare%20160cc%20och%20150cc%20och%2040cc.jpg)
No. | FMM No. | RSK | Description |
---|---|---|---|
1 | 35730000 | 8591928 | On/off handle |
2 | 35710000 | 8591929 | Eco indicating sleeve |
3 | 35900000 | 8586325 | Ceramic on/off headwork |
4 | S600275 | 8397029 | Thermostatic cartridge, complete, incl. service tool |
5 | 38680009 | 8591701 | Filter kit incl. o-rings and service tool |
6 | 59590000 | 8591930 | Scalding protection ring |
7 | 35740000 | 8591931 | Temperature handle |
8 | 59800000 | 8591543 | Inlet connectors, 160 c/c |
8 | 59810000 | 8591544 | Inlet connectors 150-153 c/c (left-handed thread) |
9 | 29830529 | 8591702 | Non-return valves, 2 pcs |
10 | 39710000 | 8591571 | Nipple M22x1-G1/2 for shower mixer |
11 | 39753000 | 8591516 | Nipple for spout |
12 | 96990000 | 8154058 | Swivel spout with integrated diverter |
13 | 38086000 | 8439701 | Locking screw |
14 | 59552410 | 8242172 | Aerator M24 ext., without air admixture |
15 | 29712000 | 8591530 | Wall bracket for 40 c/c mixers, complete |
16 | 59820000 | 8591545 | Inlet connector for 40 c/c mixer |
17 | 38521000 | 8295345 | Stop ring |
modal.bvb.desc;
![](/ui-dist/images/symbol-energy-class.png)
Accepted installation instructions
Safe Water Installation (Säker Vatteninstallation) is a set of industry* regulations to safeguard the quality of sanitary installations, prevent injury and damage and ensure compliance with the building regulations of the Swedish National Board of Housing, Building and Planning (Boverket).
![](/ui-dist/images/symbol-safe-water--2021.jpg)
Leadfree
Lead Free means that we have eliminated the lead that is normally found in brass alloys. This will reduce environmental impact of the products. Products classified as Lead Free contain less than 0.1 % lead.
![](/ui-dist/images/symbol-lead-free-en.png)
Energyclass
Energy labelling is an objective rating system that shows exactly how much energy a mixer uses. The system was developed by a number of players including sanitary fittings manufacturers, building companies, property owners and authorities such as the Swedish Energy Agency. It is based on standardised laboratory tests and certification rules. Its aim is simple: to offer impartial help for buyers, installation firms, air conditioning consultants and consumers. The mixer’s energy performance is assessed by measuring and registering water pressure, mixed water temperature and flushing time for twelve different activities. The values registered for each of these activities are added together to obtain a total energy consumption value, which is displayed on the label. This total value determines the mixer’s energy rating.
![](/ui-dist/images/symbol-energy-class.png)
